BZZ series cycloid hydraulic s
当前位置：首页 >> BZZ series cycloid hydraulic s| 045 series--- Flow Amplifying Series | ||
|
|
||
|
发布日期：[2015/1/18 14:29:28] 点击率：[4139] 来源：济宁力科液压有限责任公司 |
||
045 series PSU is a flow amplifying PSU. It has small displacement and low input torque at the low steering speed. At the quick steering speed, it has a large displacement. The displacement includes: 630. 800. 1000 、 1250ml/r. It is typical used in heavier engineering vehicles. Features The optimum design of spool and sleeve gains better characteristics. Low hydraulic noise Special casting design for low pressure drop Basic system _ load sensing Main Specification Data Max. system pressure……………16MPa Max. back pressure……………2.1MPa Input torque…………………2.8～4.0Nm Max. system operating temperature……………93°C Recommended oil filtration…………ISO 18/13
|
||
|
|
||
